SLC611-Z ZigBee Power Meter with Relay
SLC611-Z
ZigBee 3.0 DIN-rail module combining wattage/kWh measurement with 10A dry-contact relay control. Measures voltage, current, power factor and active power, supports switch input and scheduled on/off.
Overview
The SLC611-Z is a device with wattage (W) and kilowatt hours (kWh) measurement functions. It allows you to control On/Off status and to check real-time energy usage via mobile App.
Key Features
- ZigBee 3.0
- Single phase electricity compatible
- Measure the instantaneous and accumulative energy usage of the connected devices
- Measures real-time Voltage, Current, PowerFactor, Active Power
- Support Energy Usage/Production measurement
- Support Switch input terminal
- Schedule the device to automatically power electronics on and off
- 10A Dry contact output
- Lightweight and easy to install
- Extend the range and strengthen ZigBee network communication
- Power-on status setting
Specifications
| Accuracy | â€100W: ±2W; >100W: ±2% |
|---|---|
| Voltage | 90~250 Vac 50/60Hz |
| Max. Load Current | 10A dry contact |
| Frequency | 50/60Hz |
| Protocol | ZigBee 3.0 (2.4GHz IEEE 802.15.4) |
| Measured Parameters | Voltage, Current, Power Factor, Active Power; W and kWh; Energy Usage / Production |
| Switch Input | Switch input terminal |
| Relay Type | 10A dry contact output |
| Mounting | DIN rail 35mm |
| Dimensions | 50.6(L) x 23.3(W) x 46.0(H) mm |
| Operating Temp | -20â to +55â (â€90% non-condensing) |
Key Benefits
Meter + Relay in One
Measures W/kWh of the connected load and switches it on/off from the App.
Switch Input Terminal
Connect an external switch for local control of the load.
Scheduled On/Off
Schedule electronics to power on/off automatically, with power-on status settings.
ZigBee Network Extender
Mains-powered router node extends range and strengthens ZigBee mesh communication.
Ideal For
Common deployment scenarios where SLC611-Z ZigBee Power Meter with Relay delivers the most value.
Hotel Room Control
DIN-rail module controls and meters lighting and appliance circuits in guest rooms.
Lighting Control with Metering
Switch lighting on/off while tracking W/kWh consumption per circuit.
Energy Submetering
Accumulative kWh measurement for per-room or per-circuit energy billing.
Scheduled Automation
Power-on status and schedules for automatic load switching.
Solar & Production Monitoring
Energy usage/production measurement for distributed energy setups.
ZigBee Mesh Expansion
Router node strengthens the ZigBee network while controlling loads.
Frequently Asked Questions
What does the SLC611-Z do?
What is the maximum load current?
Does it support energy production measurement?
Can it be scheduled to switch automatically?
What is the switch input terminal used for?
