CB432-DP Din-rail Relay (Double Pole)
CB432-DP
ZigBee 3.0 double-pole din-rail relay with energy metering â breaks both neutral and live for safer zone control.
Overview
The Din-Rail Circuit Breaker CB432-DP is a device with wattage (W) and kilowatt hours (kWh) measurement functions. It allows you to control special zone On/Off status as well as to check real-time energy usage wirelessly via your mobile App.
Key Features
- ZigBee 3.0, works with any standard ZigBee hub
- Double-break relay â neutral and live wire disconnection
- Energy consumption measuring (W and kWh)
- 50A maximum load current
- Extends the range and strengthens ZigBee network communication
Specifications
| Protocol | ZigBee 3.0 (2.4GHz IEEE 802.15.4) |
|---|---|
| Relay Type | Double break (neutral and live) |
| Voltage | 100~240 Vac 50/60 Hz |
| Power Consumption | < 1W |
| Accuracy | †100W: ±2W; > 100W: ±2% |
| Max. Load Current | 50A |
| Measured Parameters | W and kWh metering |
| Operating Temp | -20â ~ +55â (†90% non-condensing) |
Key Benefits
Double-Pole Disconnect
Breaks both neutral and live for safer zone control.
Energy Metering
W and kWh measurement with ±2W/±2% accuracy.
50A Rating
Handles high-current circuits.
ZigBee 3.0
Works with any standard ZigBee hub.
Ideal For
Common deployment scenarios where CB432-DP Din-rail Relay (Double Pole) delivers the most value.
Safer Zone Control
Double-pole disconnect for equipment isolation.
Special Load Circuits
50A rating for heavy appliances and machinery.
Energy Sub-metering
W/kWh metering on high-current circuits.
Hotel & Commercial Panels
Controlled breakers with ZigBee monitoring.
Retrofit Distribution Boards
Drop-in DIN-rail module for existing panels.
OEM / ODM Projects
OEM branding and ODM development available.
Frequently Asked Questions
What is the CB432-DP?
Does it measure energy?
What is the maximum load?
Which ZigBee profile does it use?
What is it used for?
