SEG-X5 ZigBee Gateway
SEG-X5
High-capacity ZigBee 3.0 gateway for up to 200 devices with stable Ethernet connection, USB power, local automation and one-step backup & transfer for gateway replacement.
Overview
The SEG-X5 ZigBee Gateway acts as a central platform for your smart home system. It allows you to add up to 200 EPs into the system (Zigbee repeaters required). Automatic control, schedule, scene, remote monitoring and control for ZigBee devices can enrich your IoT experience.
Key Features
- ZigBee 3.0, connects up to 200 EPs (min. 24 ZigBee repeaters required)
- BLE 4.2 (optional)
- Stable internet connection via Ethernet
- ZigBee coordinator of the home area network and provide stable ZigBee connection
- Flexible installation with USB power
- Built-in buzzer
- Local linkage, scenes, schedules
- High-performance for complicated calculation
- Real time, efficiently interoperability and encrypted communication with cloud server
- Support backup & transfer to replace gateway โ existing sub-devices, linkage, scenes and schedules synchronize to the new gateway in easy steps
- Reliable configuration via Bonjour
Specifications
| CPU | MTK7628 |
|---|---|
| Flash ROM | 32MB |
| RAM | 128MB |
| Ethernet | 10/100M bps RJ45, Auto MDIX |
| BLE | 4.2 (Optional) |
| Protocol | ZigBee 3.0 (2.4GHz IEEE 802.15.4) + Ethernet; BLE 4.2 optional |
| Device Capacity | Up to 200 EPs (min. 24 ZigBee repeaters); 32 end devices without repeaters |
| RF Range | Outdoor: 100m (open area) |
| Antenna | Internal PCB antenna |
| Power Supply | Micro-USB DC 5V/2A |
| Dimensions | 133(L) x 91.5(W) x 28.2(H) mm |
Key Benefits
Ethernet Stability
10/100M wired connection โ stable, low-latency uplink for commercial deployments.
200-Device Capacity
Connects up to 200 ZigBee endpoints for multi-room and multi-floor projects.
Backup & Transfer
One-step gateway replacement โ sub-devices, linkages, scenes and schedules sync automatically.
USB Power, Buzzer
Flexible Micro-USB 5V/2A power with built-in buzzer for local feedback.
Ideal For
Common deployment scenarios where SEG-X5 ZigBee Gateway delivers the most value.
Hotel Room Automation
200-device ZigBee network for synchronized control across guest rooms.
Apartment & Care Facilities
Stable Ethernet uplink and local automation for care and multi-unit buildings.
Commercial Building Control
Centralized lighting, HVAC, sensor and energy management across zones.
BMS Integration
Open server API and gateway API connect to BMS and property management systems.
Energy Monitoring Systems
Real-time data from meters and thermostats for optimization logic.
Large-Scale Deployments
High capacity plus backup & transfer make fleet replacement painless.
Frequently Asked Questions
What role does this gateway play in multi-room building control systems?
Why is this gateway suitable for projects like hotels, apartments, and nursing homes?
How does Ethernet connectivity benefit system integrators?
Can the gateway support centralized device management across multiple rooms or floors?
How does the gateway support integration with third party systems?
What advantages does local control bring in building projects?
How does this gateway support energy management use cases?
