PCT501 ZigBee Programmable Communicating Thermostat
PCT501
ZigBee HA1.2 programmable communicating thermostat with 3-inch LCD, temperature and humidity display, 7-day programming and single-stage heating/cooling control.
Overview
The PCT501 is a ZigBee programmable communicating thermostat with a 3-inch LCD display, temperature and humidity sensing, and single-stage heating/cooling control.
Key Features
- ZigBee HA1.2 compliant (HA)
- Temperature remote control (HA)
- Single stage heating and single cooling control
- 3" LCD display
- Temperature and humidity display
- Supports 7-day programming
- Multiple HOLD options
- Heating & cooling indicator
- Built-in 500mAh Li-ion backup battery
Specifications
| CPU | ARM Cortex-M3 |
|---|---|
| Protocol | ZigBee 2.4GHz IEEE 802.15.4 (HA1.2) |
| Display | 3" LCD (128 x 64 pixels) |
| Measured Parameters | Temperature and humidity display |
| Programming | 7-day programming with multiple HOLD options |
| Battery | Built-in Li-ion 500mAh |
| Power Supply | AC 24V; rated power 1W |
| Data Interface | UART (Micro USB port) |
| Dimensions | 120(L) x 22(W) x 76(H) mm |
| Weight | 186g |
| Stages | Single heating and single cooling; HEAT-OFF-COOL |
| Mounting | Wall mounting |
Key Benefits
7-Day Programming
Schedule heating and cooling across the week with multiple HOLD options.
3" LCD + Humidity
128x64 LCD showing temperature, humidity and heating/cooling status.
Li-ion Backup
500mAh built-in battery keeps settings safe during power loss.
ZigBee HA1.2
Remote control and monitoring through compatible ZigBee systems.
Ideal For
Common deployment scenarios where PCT501 ZigBee Programmable Communicating Thermostat delivers the most value.
Residential Heating Control
Programmable single-stage heating/cooling for everyday comfort.
ZigBee Smart Home Integration
Remote temperature control through compatible ZigBee systems.
Small Commercial Spaces
Simple, reliable wall-mounted control for offices and retail.
Retrofit Installations
Standard wall mounting with AC 24V hardwired power.
Vacation Homes
7-day programming plus HOLD options for away periods.
OEM / ODM Projects
OEM branding and ODM development available.
Frequently Asked Questions
What does the PCT501 control?
Does it support scheduling?
What protocol does it use?
What is displayed on the screen?
How is it powered?
