PC4713-W-E-TY/3W three-phase three-wire (3P3W) wiring

PC4713-W-E-TY/3W only

Three phases without a neutral, used in older industrial distribution. Only the /3W model supports this system, and only two CTs are needed: the middle phase carries no clamp.

Isolate the supply before touching any conductor. Wire colours in the clip are the demo panel's, not a requirement.

Step by step

  1. 1 Isolate the supply and prove the conductors dead.
  2. 2 Clip CT1 on L1 and CT3 on L3; the middle phase gets no CT.
  3. 3 Land L1 on A, L2 on B and L3 on C. There is no neutral in this system.
  4. 4 Land CT1 on IA+ / IA- and CT3 on IC+ / IC-.
  5. 5 Restore power and check all three voltages plus both current channels.

Terminal reference

Power block N/C/B/A
A = L1, B = L2, C = L3. N unused in a three-wire system.
CT block IA+ IA-
Secondary of CT1, the clamp on L1.
CT block IC+ IC-
Secondary of CT3, the clamp on L3. IB stays unused.

Before you start

  • This system is only supported on the PC4713-W-E-TY/3W. The PC4713-W, -485, -TY and -E-TY models list three-phase three-wire as not supported.
  • Never land a neutral on N in a three-wire system: there is none to land.

Common mistakes

  • Buying the Open API models for a three-wire panel: they cannot report it.
  • Fitting a third CT on the middle phase: the channel is not used and the reading is misleading.
